TF – Series Residential Membrane Elements

AXEON TF – Series Residential Membrane Elements are recognized as one of the industry’s most reliable and highest performing membrane elements that deliver consistent quality and performance. Advanced manufacturing processes and utilization of the industry’s leading film technology allows these elements to deliver consistent results that equipment suppliers and water treatment dealers have come to rely on.

AXEON TF – Series Residential Membrane Elements deliver consistent results for higher quality water. All elements are shipped dry for an indefinite shelf life, easier handling and a lighter shipping weight.

Contact us today for availability or a quote
  • 200357

    TF – 1812 – 25
  • 200358

    TF – 1812 – 35
  • 200359

    TF – 1812 – 50
  • 200360

    TF – 1812 – 75
  • 200361

    TF – 1812 – 100
  • 200362

    TF – 1812 – 150
  • 208795

    TF – 1812 – 200
  • 208802†

    TF – 3012 – 500
  • 200357

    50 / 3.40
  • 200358

    50 / 3.40
  • 200359

    50 / 3.40
  • 200360

    50 / 3.40
  • 200361

    60 / 4.13
  • 200362

    65 / 4.48
  • 208795

    65 / 4.48
  • 208802†

    70 / 4.80
  • 200357

    25 / 3.94
  • 200358

    35 / 5.52
  • 200359

    50 / 7.88
  • 200360

    75 / 11.83
  • 200361

    100 / 15.77
  • 200362

    150 / 23.66
  • 208795

    200 / 31.50
  • 208802†

    500 / 78.86
  • 200357

    98
  • 200358

    98
  • 200359

    98
  • 200360

    98
  • 200361

    98
  • 200362

    98
  • 208795

    92
  • 208802†

    98
  • Membrane Type

    Polyamide Thin–Film Composite

    pH Range, Continuous Operation*

    2 – 11
  • Maximum Operating Temperature (°F / °C)

    113 / 45

    Maximum Feed Silt Density Index (SDI)

    5
  • Maximum Operating Pressure (psi / bar)

    150 / 10

    Chlorine / Chloramine Tolerance (ppm)

    0
  • Maximum Feed Flow Rate (gpm / lpm)

    2 / 7.60
  •

    8 / 30.28†
* Maximum temperature for continuous operations above pH 10 is 95°F / 35°C.
  • Description

    TF – 1812 – 25TF – 1812 – 35TF – 1812 – 50TF – 1812 – 75TF – 1812 – 100TF – 1812 – 150TF – 1812 – 200TF – 3012 – 500
  • A

    11.75 / 298.4511.75 / 298.4511.75 / 298.4511.75 / 298.4511.75 / 298.4511.75 / 298.4511.75 / 298.4511.75 / 298.45
  • B

    10.00 / 254.0010.00 / 254.0010.00 / 254.0010.00 / 254.0010.00 / 254.0010.00 / 254.0010.00 / 254.0010.50 / 266.7
  • C

    0.86 / 21.840.86 / 21.840.86 / 21.840.86 / 21.840.86 / 21.840.86 / 21.840.86 / 21.840.75 / 19.05
  • D

    0.88 / 22.350.88 / 22.350.88 / 22.350.88 / 22.350.88 / 22.350.88 / 22.350.88 / 22.350.50 / 12.70
  • E

    1.57 / 38.101.78 / 45.211.78 / 45.211.78 / 45.211.78 / 45.211.82 / 46.231.82 / 46.232.90 / 73.66

Warranty Evaluation Test Conditions: Permeate flow and salt rejection based on the following test conditions – 550 ppm, filtered and dechlorinated municipal tap water, 77°F / 25°C, 15% recovery and the specified operating pressure. Minimum salt rejection is 96%. Permeate flows for warranty evaluation may vary +/-20%. Maximum pressure drop at 13 psi / 0.9 bar.

All TF – 1812 Residential Membrane Elements seal at a standard 2.00 inch – 2.05 inch I.D. within membrane housings.

Under certain conditions, the presence of free chlorine, chloramines and other oxidizing agents will cause premature membrane failure. Since oxidation damage is not covered under warranty, the manufacturer recommends removing all oxidizing agents by pretreatment prior to membrane exposure. Please contact the manufacturer or your supplier for more information.

It is recommended that systems using these elements rinse the elements for 24 hours, prior to first use, to meet NSF/ANSI 58 Standard. The first full tank of permeate must be discarded. Do not use this initial permeate for drinking water or food preparation. Keep elements moist at all times after initial wetting. To prevent biological growth during prolonged system shutdowns, it is recommended that membrane elements be immersed in a preservative solution. Rinse out the preservative before use. For membrane warranty details, please contact the manufacturer or your supplier for more information.

If operating limits and guidelines given in this product specification sheet are not strictly followed, the warranty will be null and void. The customer is fully responsible for the effects of incompatible chemicals and lubricants on elements. Use of any such chemicals or lubricants will void the warranty. These membranes may be subject to drinking water application restrictions in some countries: please check the application status before use and sale. These elements have not been through the French approval process for use in potable water. The use of this product in and of itself does not necessarily guarantee the removal of cysts and pathogens from water. Effective cyst and pathogen reduction is dependent on the complete system design and on the operation and maintenance of the system.
